Product Detail Name : Geomembrane Welder LST 800
LST800 hot wedge welding machine is small, light, high welding efficient. It is available for welding HDPE, LDPE ,EVA ,PVC, ECB, PP and other hot melt materials.
Technical Parameters ：
Model
LST 800
Voltage
220V±5%
Power
800W
Welding speed
0.5-5m/min
Heating temperature
0-450°C
Thickness of material
0.2mm1.5mm
Overlap width
10cm
Welding width
12.5mm×2, interior cavity 12mm
Seam strength
≥85% base material (tensile resistant in shear direction)
WeightWeight
5kgs
Insulation class
class II
Usage
for welding PE PVC and other hot melt materials
Produck detail Name : Geomembrane Welder LST 800D
LST800D hot wedge welding machine is small, light, high welding efficient. It is available for welding HDPE, LDPE ,EVA ,PVC, ECB, PP and other hot melt materials. Applications:
Technical Parameters ：
Model
LST 800D
Voltage
220V±5%
Frequency
50/60Hz
Power
800W
Welding speed
0.5-5m/min
Heating temperature
0-450°C
Thickness of material
0.2mm1.5mm
Overlap width
10cm
Welding width
12.5mm×2, interior cavity 12mm
Seam strength
≥85% base material (tensile resistant in shear direction)
WeightWeight
5kgs
Insulation class
class II
Usage
for welding PE PVC and other hot melt materials
Product Detail Name : Geomembrane Welder LST 900
LST 900 Hot wedge sealer is powerful with high welding speed and good welding quality.It is available for welding over 1.0mm HDPE, LDPE ,EVA ,PVC, ECB, PP and other hot melt materials.
Applications:
Technical Parameters ：
Model
LST 900
Voltage
220V±5%
Power
1800W
Welding speed
0.5-5m/min
Heating temperature
0-450°C
Thickness of material
1.0mm 3mm
Overlap width
12cm
Welding width
15mm×2, interior cavity 15mm
Seam strength
≥85% base material (tensile resistant in shear direction)
WeightWeight
13kgs
Insulation class
class II
Usage
for welding PE PVC and other hot melt materials
Geomembrane Welder LST 900D
Subtaile for Wedding PP/PE plates, vessels and chemikal tanks, make the plastic material and fabrication .
